procedure which disregards all the
effects previously listed can lead to
significant overestimation of stresses.
References
T. Collotta, G. Barbieri, M. Mapelli
(2010) “Shotcrete Tunnel Linings
with Steel Ribs: Stress Redistribu-
tion due to Creep and Shrinkage”,
Proc. 3rd Intern. Conf. on Engineer-
ing Developments in Shotcrete,
New Zealand.
Comité Euro-International du Béton
(CEB), 1991. CEB-FIP Model
Code 1990. Final Draft, CEB Bul-
letin d’Information, N. 203, July
1991, Lausanne.
Ghali, A., Favre, R. & Elbadry, M.,
2002. Concrete Structures. Stresses
and Deformations, 3rd ed., Spon
Press, London & New York.
Roberto Acerbis, Geotechnical
Engineer, SPEA SpA, Via G. Vida 11
Milan (Italy), tel. (+39) 02 28007268,
roberto.acerbis@spea.autostrade.it
Harry Asche. Technical Leader
Tunnels, Aurecon, 32 Turbot Street
(Locked Bag 331)
Brisbane Queensland 4001
Australia, tel. (+61) 7 3173 8808,
ascheh@ap.aurecongroup.com
Guido Barbieri, Head of Geotechnical
Monitoring and Engineering
Analyses Office, SPEA SpA, Via G.
Vida 11 Milan (Italy), tel. (+39) 02
28007466,guido.barbieri@spea.
autostrade.it
Tiziano Collotta, Head of Geoengi-
neering Department, SPEA SpA,
Via G. Vida 11 Milan (Italy),
tel. (+39) 02 28007475,
email:tiziano.collotta@spea.auto-
strade.it
Table 1. Ring beam - computed axial forces
Ring N1
[kN]
N2
[kN]
N3
[kN]
N4
[kN]
N5
[kN]
N5/N1
[-]
III 1415 1600 2425 2740 3950 2.8
Table 2. Tunnel lining - computed axial forces
Sez.. N1
[kN]
N2
[kN]
N3
[kN]
N4
[kN]
N5
[kN]
N5/N1
[-]
1.1-1.2 1650 1985 3290 3645 3645 2.2
2.1-2.2 1240 1580 2170 2585 2585 2.1
3.1-3.2 190 515 580 1095 1095 5.7
4.1-4.2 2100 2440 3830 4155 4155 2.0
5.1-5.2 2530 2865 4634 4925 4925 2.0
