purchased programs, specialty-written
code, or open-source solutions.
ETL processes
extract
the data from
the datalogger,
transform
it into a for-
mat that the storage system can input,
then
load
the data into the specific
file (database, text file) for long term
storage, post-processing, or graph-
ing. Depending on the ETL needs,
commercially available programs that
perform these tasks can add $1,000
to over $10,000 to the budget of a
job. Configuration and programming
of these programs requires labor, in
addition to the cost. The type of ETL
process will influence power-usage
requirements, datalogger design, data
storage design, and telemetry design.
Manual data downloads / uploads, an
admittedly low-tech variety of ETL,
are outside the scope of this discus-
sion.
The following questions should be
answered when designing an ETL
system:
1. How much data will the telemetry
system handle?
a. Are there increased costs for
additional data transfer?
2. Is there a need for near-real time
data from the system?
a. If not, what frequency of
readings and downloads are
required?
3. What are the power requirements
from the datalogger components?
a. Will more frequent downloads
deplete the battery?
b. Will more frequent readings or
continuous readings deplete the
battery?
4. How should the data “look” once it
has been transformed?
a. What format does the data need
to be in?
5. How is the data loaded into
whatever storage system that is
established?
a. Is data appended to a text file?
b. Is data loaded into an existing
or new database?
6. What are the server storage space /
processing power needs?
a. Are more frequent readings
going to fill the storage or require
more processing time?
7. How frequently is the data being
examined?
8. Are alarms established based on
this data?
Answering these questions will
prompt iterative reviews of the data
transfer design. For example, a need
for additional download frequency
may change the plan for data telem-
etry, or a need for more frequent read-
ings may prompt the installation of
additional solar panels to meet power
requirements.
Common methods of ETL
Commercially available programs
ETL is most commonly setup with
commercially available programs,
usually written by a vendor. Some
examples include; LoggerNet from
Campbell Scientific, Cloud and
Enterprise from Sensemetrics, and
DEX from dataTaker. These programs
typically take care of the Extract and
Transform part of the ETL process.
They can be scheduled to commu-
nicate with the datalogger,
extract
the data, and
transform
the data to a
format of your choice. Most of these
programs can
load
the data into some
storage format, whether it is a text
file or proprietary database. These
programs cannot load data into an
internally developed database, as
they would not “know” the database
setup. These programs need to run on
a computer, virtual machine, or cloud
service.
Some advantages of using commer-
cially available programs are:
1. They typically take care of the
connections to the datalogger with
relative ease.
2. They can handle difficult com-
munications settings and net-
works, including configurations to
download data at a specific time or
repeat downloads if the downloads
were unsuccessful.
3. Typically, they have some (but not
full) functionality to control the
format of the data.
Some disadvantages of using commer-
cially available programs are:
1. You will need to configure your
database uploading function to
process the data as formatted by
the program.
2. Only the manufacturer provides
updates and support, as needed.
Purpose-written code
Code written specifically for the
application is another commonly
available ETL process. This purpose-
written code can be more agile and
flexible than a vendor program, and
can automate any or all the required
ETL processes. For example, when
using a commercially available pro-
gram like Loggernet to connect to the
datalogger and save the data into a text
file, a piece of code could be writ-
ten to upload this data into a specific
database. In this example, Loggernet
would be performing the Extraction
and Transforming parts of ETL, and
the piece of code would be performing
the Loading part. With more control of
the process, the data can be saved in
the format best suited for the project
or application.
Advantages of using purpose-written
code are:
1. Control of the format of the data.
2. Capability to automate the neces-
sary data transfer steps, including
loading into a database.
3. Not paying for functions of a sys-
tem that aren’t used.
4. Not beholden to any costly forced
updates or lack of support for an
older product.
Disadvantages of using purpose-writ-
ten code are:
1. More time possibly spent in man-
hours to develop the code than the
cost of a commercially available
project.
